- TAA-Compliant: Yes
- Image Enhancement Technology: Visioneer OneTouch with Acuity
- Weight with Accessory 11.5 lbs.
- Simplex or Duplex: Duplex (two side scanning)
- Standard Warranty: 3 year
- Optical Resolution: 600 dpi
- ADF Capacity: 100 sheets (20 lb. paper)
- Visioneer OneTouch Technology (PC): Yes
- Duty Cycle: 10,000 pages/day
- Dimensions: 12.5 x 6.6 x 7.5 in (W×D×H)
- Output Bit Depth: 24/8/1
- Scan Method: ADF Duplex
- Light Source: LED (light emitting diode) instant on
- Maximum Paper Size: 9.5 x 240 in
- Drivers: PC: TWAIN, ISIS, WIA
- Enhanced Resolution (Interpolated): 75, 100, 150, 400, 500, 600, 1200 dpi
- Imaging sensor: CIS (charged imaging sensor)
- Paper Thickness/Weight: 7-110 lbs
- Background Color: Gray
- Minimum Paper Size: 2 x 2 in
- Speed @ 300 dpi: 50 ppm / 100 ipm color
Visioneer Patriot PD45
- 50 ppm / 100 ipm speeds @ 300 dpi
- 10,000-page daily duty cycle
- 100-sheet automatic document feeder
- Visioneer Network Scan Service
- Visioneer Mobile Capture app
- TAA U.S. government compliant
Staying ahead of the scanner technology curve doesn’t have to mean overspending on document capture hardware and software. With the Visioneer® Patriot™ PD45 Scanner, get the performance and value combination that delivers the return-on-investment modern organizations are looking for. Ideally suited to healthcare, legal, government and financial services sectors that are document-heavy and focused on privacy and document security, the Patriot™ PD45 duplex color scanner has the speed and paper handling capabilities to get the job done. Plus, with network and mobile connectivity, document capture with the Patriot™ PD45 can be as flexible as the workday requires.
Delivering scan speeds of 50 pages (100 impressions) per minute at 300 dpi, the Patriot™ PD45 is both fast and accurate. Get better-than-original quality scans at full speed with Visioneer Acuity, while Visioneer OneTouch® provides preset profiles and walk-up scanning capability. For jobs that require extra attention, Visioneer Capture SE makes batch scanning, editing, even barcode reading and data extraction simple. Manage archived data intelligently with Visioneer Organizer AI’s automated file classification, and put ABBYY® FineReader® PDF (full version) to work with searchable PDFs, optical character recognition (OCR), file conversions and security. With over $1,000 in software included, implementing the Patriot™ PD45 is a no-brainer.
Visioneer VAST Network© brings network connectivity and scanner sharing to the USB-connected Patriot™ PD45, while the Visioneer Mobile Capture app makes document capture, editing and secure sharing on a smart phone or tablet a reality. The Patriot™ PD45 delivers unrivaled technology value to meet the business needs of today and tomorrow.
- Intel® i3 or equivalent processor
- Internet access (for installation only)
- Windows® 11 / 10 / 7
- USB port
- 2GB of RAM
- Minimum available hard disk space:
- 350 MB for the scanner driver
- 1 GB for Visioneer OneTouch
- 1 to 3 GB for each additional application
Standard Service and Support Warranty – Included with purchase
• Technical response line phone support
• CareAR® Assist
• 24/7 web support
• Return & replace RMA process
Windows User Guides
Visioneer Network Scan Service Guides
Windows Patriot H70 & Patriot D45 Scanner User Guide
Windows Patriot PD45 Guides
Drivers for Windows
Visioneer Update for Windows
Visioneer Update will automatically detect your scanner and check for the latest drivers and bundled software. You may choose to use Update or you may download only the driver and software you need from the links below. Be advised that many of the bundled software packages can only be downloaded through Visioneer Update or the installation DVD. For technical support, please contact us.
Visioneer Network Scan Service for Windows 11, 10, 7
Share your USB-connected scanner with any PC user over your LAN/wireless network.
– Service version: 184.108.40.2060
– Bonjour version: 220.127.116.11
Visioneer Network Driver for Windows 11, 10, 7
Scan over your LAN/wireless network (requires installation of TWAIN and WIA drivers).
– Driver version:5.1.723.1113
– Bonjour version: 18.104.22.168
PD45 DriverPLUS (TWAIN, WIA, ISIS) with Acuity Combo Installer
Microsoft Windows 11, 10, 7 certified TWAIN and WIA drivers
– Driver version: 22.214.171.12476
– Acuity version: 5.1.2220.11203
– Multilingual (ES)
Xerox DocuShare 7.x link for Visioneer OneTouch 4.x software
This link allows documents to be sent directly from Visioneer OneTouch to Xerox DocuShare 7.x software.
NOTE: Prior to installing the link, please download and install the latest version of Xerox DocuShare Drive at Xerox Docushare Downloads
OneTouch 4.x software for OneTouch and button scanning
Visioneer OneTouch is a utility that connects scanner buttons with pre-selected destinations (and/or applications) and allows you to scan into these destinations by simply pressing one button. Destinations can include your email, Word processor, printer or simply a file folder.
Please note: Support for Windows 2000 has ended with OneTouch 4.5
